NOVALAM S 550 - Solventless laminator

•
•

A cost-effective, compact, solventless laminator, the NOVALAM S 550 is the perfect choice for converters. Incorporating a patented, automatic integrated washing system and the unique BOBST three column layout for maximum accessibility. With plug and play installation, the NOVALAM S 550 can be in production, 5 days after arrival at the customer's site. Every converters choice.

Versatile, flexible and ready to start

• Designed to handle a variety of substrates including thin alu-foil, metallized film and thin stretchable materials
• Equipped with sleeve transfer rollers for easy and fast job changeover
• Plug & play installation - no foundation needed, averages 1 week from arrival to production
• Standard web widths: 1030 - 1330 - 1530 mm. Other web widths available as option.
• Lamination speed up to 450 m/min
• 4.0 industry ready for post processing data.

Productivity & quality from short runs upwards

• Job changeovers completed in minutes without tools irrespective of configuration:
  • on-board rotating cantilever system for sleeve type roll

• Pneumatic opening of metering roller for quick and easy adhesive disposal
• Automatic reel centering system reducing waste and start-up time:
  • one touch winder setup
  • quick fine tuning after web threading
  • perfect reel alignment with linear encoder
  • no telescopic effect

• Patented fully integrated automatic washing as standard supply
• 3-roller laminating nip for superior optical quality of coated adhesive
• 2 heated rolls for  optimal process temperature control
• Independent setting of thermal regulation for coating unit and metering rolls.

Cost optimization and easy operation

• Patented design of long-life side retainers improves the laminator's efficiency and decreases costs
• Layout enabling full accessibility to the laminating nip for quality and process inspection without stopping the machine
• Adhesive mixer solutions for effective adhesive quantity control, matching production requirements
• Micrometric adjustment for perfect coating adhesive distribution
• Fully integrated HMI
• Intuitive, easy to read pictogram and commands for the setting, display and storage of individual job working parameters.
